Unexpected complication of stent-assisted aneurysm coiling in presence of complex anatomical variation

Last update on November 28, 2022

Discover how Dr. Ray Nirmalya treated an unexpected complication of stent-assisted aneurysm coiling with a complex anatomical variation in a 50-year-old female patient.

Case presentation
  • 50 y/F.
  • No known comorbidities.
  • Sudden onset headache and vomiting.
  • GCS = 15/15
  • Head CT - grade-4 SAH
  • Planned for DSA >
You do not have permission to view this object.

RVA AP

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical-2

RVA LAT

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical-3

LVA  AP

You do not have permission to view this object.

LVA LAT

You do not have permission to view this object.

RCCA  AP /  RCCA  LAT

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation

RICA  AP

You do not have permission to view this object.

RICA  LAT

You do not have permission to view this object.

SIMULTANEOUS RVA AND LICA RUN

AP

You do not have permission to view this object.

LAT

You do not have permission to view this object.

SIMULTANEOUS RVA AND LICA  3D RA

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical-10

You do not have permission to view this object.
Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation



Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation

ANGIO CT REFORMAT

You do not have permission to view this object.

Summary of angiographic findings

  • Ruptured wide-necked basilar tip aneurysm.
  • Persistent left-sided trigeminal artery joining the left superior cerebellar artery.
  • The right ICA is not visible beyond the ophthalmic artery.
  • The left ICA is attenuated after the left PTA.
  • The right PCoM is hypertrophied and supplies the right anterior circulation.
  • The left anterior circulation fills from the right anterior circulation through ACoM.
Treatment options
  • BALLOON-ASSISTED COILING
  • STENT-ASSISTED COILING
  • FLOW DIVERSION
  • INTRASACCULAR DEVICES WITH OR WITHOUT ASSISTANCE



WORKING PROJECTION /  LASER CUT STENT DEPLOYED FROM RIGHT P1 TO BASILAR

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation



POST-COILING CHECK ANGIOGRAM

Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation



POST-COILING ANGIO CT

You do not have permission to view this object.

POST-COILING SIMULTANEOUS RVA AND LICA RUN

RVA  AP

You do not have permission to view this object.

LICA  AP

You do not have permission to view this object.
Unexpected complication of stent assisted aneurysm coiling in presence of complex anatomical variation



FOLLOW-UP

  • Patient was extubated in ICU at POD1.
  • MAP kept above 100 mm of Hg.
  • ON POD2, developed right hemiparesis.
  • CT-left MCA infarct.
You do not have permission to view this object.

RVA AP POD 2

You do not have permission to view this object.

LICA AP POD 2

You do not have permission to view this object.
  • After one year of follow-up, the patient has minor weakness in the right upper and lower limbs.
  • Complete exclusion of the aneurysm.
You do not have permission to view this object.
Conclusion
  • After stent-assisted coiling, there is a preferential redirection of flow into the right hemianterior circulation, and a reduction in flow through the ACoM, compromising the left MCA branches.
  • Altering natural physiological variation can always be tricky and should be dealt carefully.
  • Understand the anatomy is the most crucial part of any neurointerventional procedure.
  • Minute findings and detailed angiographic understanding can help in treating and prognosticating patients.
