Recanalization of symptomatic chronic ICA occlusion using Angioplasty, Stenting, and Rheolytic Thrombectomy

Last update on February 16, 2024

Embark on the journey of a 75-year-old male with transient neurological symptoms and a history of cardiovascular disease, undergoing intricate endovascular intervention for an occluded left internal carotid artery. Witness the meticulous steps involved in recanalization, showcasing the unique challenges of managing recurrent large vessel occlusion refractory to medical treatment.

Case presentation
  • 75 yo male with slurred speech, aphasia, and left eye blurry vision
    • Resolved spontaneously within few minutes
  • Hx of HTN and CAD with cardiac stents
  • CT head: no intracranial abnormalities
  • CTA head and neck: no LVO; occluded left ICA at the origin
  • CTP: large area of perfusion deficit with increased Tmax in the left MCA and PCA distribution



Equipment used

  • Femoral access
  • Guide cath: 6F Neuron Max 088
  • Diagnostic cath: 5F Penumbra Simmons 2
  • Microwire: V-18 (018); Whisper wire 014
  • Microcath: Prowler Select Plus 021
  • EPD: Spider 5mm
  • Balloon / Stent / AngioJet device



First run

First run (AP)
First run (Lateral)



Crossing with V18 wire

You do not have permission to view this object.

Advancing microcatheter

You do not have permission to view this object.



Microcatheter run

Microcatheter run

Embolic protection device (Spider 5mm) advanced over 014 Whisper wire

You do not have permission to view this object.



Viatrac 14 Plus balloon 4x40mm (x2)

You do not have permission to view this object.
You do not have permission to view this object.



Run post Angioplasty x2

You do not have permission to view this object.



Protégé stent 10x40mm

Protégé stent 10x40mm
Protégé stent 10x40mm



Telescoped another Protégé stent 10x40mm

Telescoped another Protégé stent 10x40mm
Telescoped another Protégé stent 10x40mm



Checkpoint

Before

Checkpoint - Before

After

Checkpoint - After



Viatrac 14 Plus Balloon 5x20mm

Viatrac 14 Plus Balloon 5x20mm

AngioJet x2

You do not have permission to view this object.



Before/After AngioJet

After AngioJet



Intravascular Ultrasound (IVUS)

You do not have permission to view this object.



IVUS Before/After

You do not have permission to view this object.
You do not have permission to view this object.
