Challenges with staged treatment of a ruptured giant aneurysm

Last update on March 2, 2023

Find out how Dr Anil K Roy treated a 65-year-old female who collapsed at work with headache, confusion, altered mental status...

Case presentation

HISTORY

  • 65 year old female collapsed at work with headache, confusion, altered mental status
  • SAH HH 3/WFNS 2



65 year old female collapsed at work with headache, confusion, altered mental status
65 year old female collapsed at work with headache, confusion, altered mental status
You do not have permission to view this object.



You do not have permission to view this object.



OPTIONS

  • Subtotal coiling followed by flow diversion versus stent-assisted coiling
  • Coiling plus flow diversion
  • Open surgical clipping
    • Proximal neck exposure needed likely with retrograde suction decompression
    • Potential need for high flow bypass



DELAYED TREATMENT STRATEGY

  • Treatment of ruptured complex and large/giant ruptured cerebral aneurysms by acute coiling followed by staged flow diversion. Brinjikji et al., JNS 2016
  • ‘Plug and pipe’ strategy for treatment of ruptured intracranial aneurysms. Howard et al., JNIS 2019





SETUP

  • 6F femoral sheath
  • Benchmark Guide
  • Echelon microcatheter
  • Synchro select 014 microwire
  • Coils – Target XL coils



You do not have permission to view this object.

THROMBUS FORMATION

  • Thrombus at parent vessel and in distal MCA branch
  • Cangrelor drip initiated
  • The use of cangrelor in neurovascular interventions: a multicenter experience. Cortez et al., Neuroradiology 2021
    • Loading dose – 15 micrograms/kg
    • Infusion – 2 micrograms/kg/minute



You do not have permission to view this object.

SUBSEQUENT COURSE

  • Cangrelor continued for a few hours
  • Delayed CT head revealed a tract hemorrhage that was stable on repeat scans



staged-treatment-ruptured-giant-aneurysm-s11-1-a-tract-hemorrhage
Delayed CT head revealed a tract hemorrhage that was stable on repeat scans



HOSPITAL COURSE

  • EVD was weaned around day 10
  • Prior to dc dual antiplatelet therapy was initiated (Aspirin 325 mg and Clopidogrel 75 mg)
    • Discontinued due to subsequent GI bleed
    • Two duodenal ulcers were subsequently found, one of which was treated with clips by the GI service
  • Eventually discharged around 1 month after admission on H pylori treatment



COURSE

  • Initiated on Aspirin/Clopidogrel after completion of H pylori treatment
  • Prolonged course of dapt completed (1 month) to ensure no recurrent GI bleed prior to planned flow diversion



FLOW-DIVERSION SETUP

  • 8F femoral sheath
  • Neuron-Max Guide
  • CAT5 intermediate
  • XT-27 microcatheter
  • Synchro select 014 microwire
  • Asahi 018 soft microwire
  • Trevo 4 x 41 for reduction of microcatheter
  • Surpass Evolve 4.25 x 25
  • Transform 7 x 7 balloon



You do not have permission to view this object.

CHALLENGES

  • Navigation required looping through the aneurysm with microcatheter
  • Initial attempt with a Synchro 014 microwire and then switched to Asahi 018
  • One coil loop was known to be across the microcatheter but given significant difficulty in finding the outflow this was left in place
  • Microcatheter reduced with a Trevo 4 x 41 stent retriever





Pre-angioplasty

You do not have permission to view this object.

 Post-angioplasty: Transform 7x7

You do not have permission to view this object.



You do not have permission to view this object.

CONCLUSION

  • Thrombus formation at the parent vessel can be seen with coiling of large and giant aneurysms – can be recognized at the time of coiling
  • Acute flow diversion in the setting of subarachnoid hemorrhage can be done although this does limit flexibility of dual antiplatelet cessation with tract hemorrhage or a GI bleed
  • Outflow navigation of microcatheter in the setting of a large coil mass with a giant aneurysm can be challenging
